FE-SUB12V2
FE-SUB12V2
| FE-SUB12V2 / 12" SUBWOOFER LOUD SPEAKER | PRICE | ||
| Pictures | General Data / Specifications | ||
| Overall Dimensions | 12 | inch |
| Nominal Power Handing / RMS | 400 | W | |
| Maximum Power | 800 | W | |
| Sensitivity | 88.7 | dB | |
| Frequency Response | 60-500K | Hz | |
| Dust Cap | Paper | \ | |
| Cone Material | Paper cone + Rubber Edge | \ | |
| Basket Materil | Steel | \ | |
| Electrical Data | |||
| Nominal Impedance | 4 | OHMS | |
| DC Resistance | 3.2 | OHMS | |
| Voice Coil and Magnet Parameters | |||
| Voice Coil Diameter | 50.8 | mm | |
| Winding Material | CCAW | \ | |
| Voice Coil Bobbin | Glass Fiber | \ | |
| Magnet System Type | Ferrite | \ | |
| Magnet Size | 156*25*2pcs | Y30 | |
| Magnet Weigth | 20 | Oz | |
| Washer Size / T yoke Size Thickness | 8 | mm | |
| Thiele & Small Parameters | |||
| Equivilant Volume | 26.548 L | VAS | |
| Free Air Resonance | 45.8 Hz | FS | |
| Mechanical Factor | 5.401 | Qms | |
| Electrical Factor | 0.708 | Qes | |
| Total Factor | 0.682 | Qts | |
| Mechanical Mass | 181.25 | Mms | |
