MI-65.4B NEO

Car Speaker > Midrange > MI-65.4B NEO

MI-65.4B NEO

This is a strong magnet model that specially design for Midrange Speaker.
For neodymium, it’s a kind of permeant magnet. It’s much lighter but magnetic stronger. The advantage of a neodymium magnet is its weighs only one-tenth as much as ferrite but has the same magnetic force as it; but the drawback is its higher price compared to ferrite. Under the action of strong magnetism, the sensitivity of the speaker will be higher at 98 dB and has vary wide frequency between 95 hertz to 10 kilo hertz. Higher sensitivity means louder sound but lighter weight. Make its sound more balanced. It is the best choice for high-end products
MI-65.4B NEO   / 6.5" NEO MIDRANGE LOUD SPEAKERPRICE$14.72
PicturesGeneral Data / Specifications
Overall Dimensions6.5inch
Nominal Power Handing / RMS200W
Maximum Power400W
Sensitivity 98dB
Frequency Response95-10KHz
Dust Cap Paper\
Cone Material Paper cone + Cloth Edge\
Basket  MaterilSteel\
Electrical Data
Nominal Impedance4OHMS
DC Resistance3.2OHMS
Voice Coil and Magnet Parameters
Voice Coil Diameter 38.3mm
Winding  Material CCAW\
Voice Coil BobbinGlass Fiber\
Magnet System Type Neodymium\
Magnet Size90*45*6N35H
Magnet Weigth\Oz
Washer Size / T yoke Size Thickness6mm
Thiele & Small Parameters
Equivilant Volume3.988 LVAS
Free Air Resonance 145 HzFS
Mechanical Factor5.38Qms
Electrical Factor0.423Qes
Total Factor0.392Qts
Mechanical Mass 10.17Mms
BL Factor8.605BL
Cone Area158.37Sd
